ET70

Combination Wrench Elliptical Type

  • Chrome Vanadium Steel
  • Chrome Plated Fully Polished Ring 15° Angled
  • Wave Profile

Finish
CPP = Chromium Plated, Fully Polished
CPS = Chromium Plated, Satin Finish

ANSI – ASME B107.6 – 1994
DIN 3113A – NE ISO 1711-3318 – 691

  • Chrome Vanadium Steel
  • Chrome Plated Fully Polished Ring 15° Angled
  • Wave Profile

Finish
CPP = Chromium Plated, Fully Polished
CPS = Chromium Plated, Satin Finish

ANSI – ASME B107.6 – 1994
DIN 3113A – NE ISO 1711-3318 – 691

Product Specifications
Article No. Size (mm) Length (mm) Weight (Grams)
ET7000603 6 100 18
ET7000703 7 110 22
ET7000803 8 120 26
ET7000903 9 130 30
ET7001003 10 140 42
ET7001103 11 150 52
ET7001203 12 160 60
ET7001303 13 170 72
ET7001403 14 180 86
ET7001503 15 190 100
ET7001603 16 200 109
ET7001703 17 210 132
ET7001803 18 220 152
ET7001903 19 230 160
ET7002003 20 240 182
ET7002103 21 250 200
ET7002203 22 260 235
ET7002303 23 270 255
ET7002403 24 280 285
ET7002503 25 290 310
ET7002603 26 300 340
ET7002703 27 310 390
ET7002803 28 320 435
ET7002903 29 330 435
ET7003003 30 340 500
ET7003203 32 360 580
AF Series
Article No. Size (Inch) Length (mm) Weight (Grams)
ET7051283 AF 1/4″ 100 18
ET7051583 AF 5/16″ 120 26
ET7051683 AF 11/32″ 130 30
ET7051883 AF 3/8″ 140 42
ET7052183 AF 7/16″ 150 52
ET7052483 AF 1/2″ 170 72
ET7052783 AF 9/16″ 180 86
ET7053383 AF 5/8″ 200 109
ET7053683 AF 11/16″ 210 132
ET7053983 AF 3/4″ 230 160
ET7054583 AF 13/16″ 250 200
ET7054883 AF 7/8″ 260 235
ET7055183 AF 15/16″ 280 285
ET7055483 AF 1″ 300 340
ET7055783 AF 1.1/16″ 310 390
ET7056083 AF 1.1/8″ 330 435
ET7056383 AF 1.1/4″ 360 580
Packing Options
Finish Options
  • CPP = Chromium Plated, Fully Polished
  • CPS = Chromium Plated, Satin Finish
Sets
  • ET70 CPP - WSet on Wall Holder with Cover
    Set on Wall Holder with Cover<br/>ET70 CPP - W
    Set on Wall Holder with Cover
    ET70 CPP - W

    Article No. Content (mm) Weight (Grams)
    ET70CPP-W/5 8-10-12-14-17 370
    ET70CPP-W/6 8-10-12-13-14-17 450
    ET70CPP-W/7 10-11-13-14-16-17-19 680
    ET70CPP-W/8 8-9-10-12-13-14-17-19 640
    ET70CPP-W/11 6-7-8-9-10-11-12-13-14-15-16 650
    ET70CPP-W/011 6-7-8-9-10-11-12-13-14-17-19 740
    ET70CPP-W/0011 6-8-10-12-13-14-15-16-17-18-19-22 1230
    ET70CPP-W/12 6-7-8-9-10-11-12-13-14-17-19-22 970
    ET70CPP-W/14 8-9-10-11-12-13-14-15-17-19-21-22-23-24 1650

    AF Series

    Article No. Content (Inch) Weight (Grams)
    ET70CPP-W/5 AF 3/8 – 7/16 – 1/2 – 9/16 – 5/8″ 400
    ET70CPP-W/9 AF 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 – 13/16 – 7/8″ 1130
    ET70CPP-W/09 AF 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4″ 640
    ET70CPP-W/11 AF 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 -13/16 – 7/8″ 1170

    Metric/AF Series

    Article No. Content (mm / Inch) Weight (Grams)
    ET70CPP-W/22 MF 6-7-8-9-10-11-12-13-14-17-19
    SAE 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 -11/16 – 3/4 – 13/16 – 7/8″    		 1180
    ET70CPP-W/24 MF 6-7-8-9-10-11-12-13-14-17-19-22
    SAE 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 -13/16 – 7/8 – 1″    		 2470
    ET70CPP-W/32 MF 6-7-8-9-10-11-12-13-14-17
    SAE 1/4 – 9/32 – 5/16 – 11/32 – 3/8 – 7/16 – 15/32 – 1/2 – 9/16 – 11/16″    		 1780
    8-10-11-13-14-16
    SAE 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8″
  • ET70 CPP - PTSet in Wallet
    Set in Wallet<br/>ET70 CPP - PT
    Set in Wallet
    ET70 CPP - PT

    Article No. Content (mm) Weight (Grams)
    ET70CPP-PT/5 8-10-12-14-17 370
    ET70CPP-PT/7 10-11-13-14-16-17-19 675
    ET70CPP-PT/8 8-9-10-12-13-14-17-19 630
    ET70CPP-PT/11 6-7-8-9-10-11-12-13-14-17-19 730
    ET70CPP-W/011 6-8-10-12-13-14-15-16-17-18-19-22 1240
    ET70CPP-PT/12 6-7-8-9-10-11-12-13-14-17-19-22 980
    ET70CPP-PT/14 8-9-10-11-12-13-14-15-17-19-21-22-23-24 1640
    ET70CPP-PT/16 6-8-9-10-11-12-13-14-15-17-19-21-22-24-30-32 2630

    AF Series

    Article No. Content (Inch) Weight (Grams)
    ET70CPP-PT/5 AF 3/8 – 7/16 – 1/2 – 9/16 – 5/8″ 360
    ET70CPP-PT/09 AF 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4″ 740
    ET70CPP-PT/9 AF 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 – 13/16 – 7/8″ 1120
    ET70CPP-PT/11 AF 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 – 13/16 – 7/8″ 1180
    ET70CPP-PT/14 AF 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 – 13/16 – 7/8 – 15/16 – 1 – 1.1/16 – 1.1/8 – 1.1/4″ 3200

    Metric/AF Series

    Article No. Content (mm / Inch) Weight (Grams)
    ET70CPP-PT/22 MF 6-7-8-9-10-11-12-13-14-17-19
    SAE 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 – 13/16 – 7/8″    		 1200
    ET70CPP-PT/24 MF 6-7-8-9-10-11-12-13-14-17-19
    SAE 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 – 13/16 – 7/8 – 1″    		 2500
    ET70CPP-PT/25 MF 6-7-8-9-10-11-12-13-14-15-17-19
    SAE 1/4 – 5/16 – 11/32 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8-11/16 – 3/4 – 13/16 – 7/8 – 1″    		 2400
  • ET70 CPP - WSet on Wall Holder with Cover
    Set on Wall Holder with Cover<br/>ET70 CPP - W
    Set on Wall Holder with Cover
    ET70 CPP - W

    Article No. Content (mm) Weight (Grams)
    ET70CPP-W/5 8-10-12-14-17 370
    ET70CPP-W/6 8-10-12-13-14-17 450
    ET70CPP-W/7 10-11-13-14-16-17-19 680
    ET70CPP-W/8 8-9-10-12-13-14-17-19 640
    ET70CPP-W/11 6-7-8-9-10-11-12-13-14-15-16 650
    ET70CPP-W/011 6-7-8-9-10-11-12-13-14-17-19 740
    ET70CPP-W/0011 6-8-10-12-13-14-15-16-17-18-19-22 1230
    ET70CPP-W/12 6-7-8-9-10-11-12-13-14-17-19-22 970
    ET70CPP-W/14 8-9-10-11-12-13-14-15-17-19-21-22-23-24 1650

    AF Series

    Article No. Content (Inch) Weight (Grams)
    ET70CPP-W/5 AF 3/8 – 7/16 – 1/2 – 9/16 – 5/8″ 400
    ET70CPP-W/9 AF 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 – 13/16 – 7/8″ 1130
    ET70CPP-W/09 AF 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4″ 640
    ET70CPP-W/11 AF 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 -13/16 – 7/8″ 1170

    Metric/AF Series

    Article No. Content (mm / Inch) Weight (Grams)
    ET70CPP-W/22 MF 6-7-8-9-10-11-12-13-14-17-19
    SAE 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 -11/16 – 3/4 – 13/16 – 7/8″    		 1180
    ET70CPP-W/24 MF 6-7-8-9-10-11-12-13-14-17-19-22
    SAE 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 -13/16 – 7/8 – 1″    		 2470
    ET70CPP-W/32 MF 6-7-8-9-10-11-12-13-14-17
    SAE 1/4 – 9/32 – 5/16 – 11/32 – 3/8 – 7/16 – 15/32 – 1/2 – 9/16 – 11/16″    		 1780
    8-10-11-13-14-16
    SAE 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8″

  • ET70 CPP - PTSet in Wallet
    Set in Wallet<br/>ET70 CPP - PT
    Set in Wallet
    ET70 CPP - PT

    Article No. Content (mm) Weight (Grams)
    ET70CPP-PT/5 8-10-12-14-17 370
    ET70CPP-PT/7 10-11-13-14-16-17-19 675
    ET70CPP-PT/8 8-9-10-12-13-14-17-19 630
    ET70CPP-PT/11 6-7-8-9-10-11-12-13-14-17-19 730
    ET70CPP-W/011 6-8-10-12-13-14-15-16-17-18-19-22 1240
    ET70CPP-PT/12 6-7-8-9-10-11-12-13-14-17-19-22 980
    ET70CPP-PT/14 8-9-10-11-12-13-14-15-17-19-21-22-23-24 1640
    ET70CPP-PT/16 6-8-9-10-11-12-13-14-15-17-19-21-22-24-30-32 2630

    AF Series

    Article No. Content (Inch) Weight (Grams)
    ET70CPP-PT/5 AF 3/8 – 7/16 – 1/2 – 9/16 – 5/8″ 360
    ET70CPP-PT/09 AF 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4″ 740
    ET70CPP-PT/9 AF 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 – 13/16 – 7/8″ 1120
    ET70CPP-PT/11 AF 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 – 13/16 – 7/8″ 1180
    ET70CPP-PT/14 AF 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 – 13/16 – 7/8 – 15/16 – 1 – 1.1/16 – 1.1/8 – 1.1/4″ 3200

    Metric/AF Series

    Article No. Content (mm / Inch) Weight (Grams)
    ET70CPP-PT/22 MF 6-7-8-9-10-11-12-13-14-17-19
    SAE 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 – 13/16 – 7/8″    		 1200
    ET70CPP-PT/24 MF 6-7-8-9-10-11-12-13-14-17-19
    SAE 1/4 – 5/16 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8 – 11/16 – 3/4 – 13/16 – 7/8 – 1″    		 2500
    ET70CPP-PT/25 MF 6-7-8-9-10-11-12-13-14-15-17-19
    SAE 1/4 – 5/16 – 11/32 – 3/8 – 7/16 – 1/2 – 9/16 – 5/8-11/16 – 3/4 – 13/16 – 7/8 – 1″    		 2400
